Specifications
| LABEL | VALUE |
| Connector Standard: | NBR 14136 |
| Maximum Current rating: | 10A, 12A, 15A, 20A |
| Maximum Voltage: | 250V |
| Number of Poles and Wires: | 3 poles, 3 wires |
| Copper Conductor Material: | Oxygen free Copper (OFCU) |
| Outer Jacket Material: | PVC, Rubber, Halogen-Free, Textile braid |
| Blade Material: | Nickel coated Brass |
| Flamability Rating: | UL 94V-0 |
| Color: | Black/White/other |
| Temperature Rating: | -40℃ ~+75℃ |
| Approvals: | INMETRO |
| Environmental Certifications: | RoHS, REACH, PAHs |
| Testing: | Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity |
| Country of Origin: | Made In China |
| Packing: | Standard Export Carton |
Available Wire Styles
| Gauge/ # Conductors | Cord Type |
| 3×0.5mm² | H03VV-F, H05VV-F, H05RR-F, H05RN-F |
| 3×0.75mm² | H03VV-F, H05VV-F, H05RR-F, H05RN-F, H05V2V2-F |
| 3×1.00mm² | H05VV-F, H05RR-F, H05RN-F, H05V2V2-F |
| 3×1.5mm² | H05VV-F, H05RR-F, H05RN-F, H05V2V2-F, H07RN-F |
